On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station

Sertifikasi
Cina Shenzhen Haiyu Optics Communication Equipment Co., Ltd. Sertifikasi
Cina Shenzhen Haiyu Optics Communication Equipment Co., Ltd. Sertifikasi
I 'm Online Chat Now

On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station

besar.img.alt
kecil.img.alt kecil.img.alt kecil.img.alt kecil.img.alt kecil.img.alt kecil.img.alt

Gambar besar :  On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station

Detail produk:
Tempat asal: Guangdong, Cina
Nama merek: Haiyu Optical
Sertifikasi: ISO9001, CE, ROHS
Nomor model: HYG-RRU-DLC-MM-040
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1-9 Potongan
Harga: $6.80
Detil Deskripsi produk
Warna kabel: Hitam Kualitas inti: 2
Mode kabel: Multimode 50 / 125um Diameter kawat: 7,0 mm
Kerugian penyisipan: <= 3,0 dB Mengembalikan kerugian: > = 35 dB
Jenis Konektor: DLC / PC Kisaran Temp Operasi: -40 ~ 85 ° C
Panjang gelombang: 850 nm Panjangnya: 40 m
Menjual unit: Item tunggal Ukuran paket tunggal: 38X38X12 cm
Berat kotor tunggal: 3.000 kg Jenis Paket: masing-masing dikemas dengan film plastik, lalu dimasukkan ke dalam karton.
Cahaya Tinggi:

Kabel Patch Serat Optik FTTX

,

Kabel Patch SC Selubung LSZH

,

Kabel Patch Serat Optik FTTH

On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station

Product Description
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 0

On sales 40M DLC multimode outdoor armour Optical fiber protected branch patch cable for 3G Base Station



Model: Optical Cable Assembly, DLC/PC, Multimode 50/125,

GYFJH 2A1a (LSZH), 7.0mm, 2cores, 0.03m/0.34m, 2mm, Outdoor Protected Branch Cable

(ARMOURED TYPE) Length= 40m

       With the continuous development of optical fiber communication technology, 3G commercial trial network, high-speed local area networks and optical access network such as the market that is a sustained manner. Especially in the 3G, 4G, and WiMax base stations and fiber-optic distributed zoom technology, ODLC fiber optic cable connector assemblies are rapidly becoming the standard connector interface.
     DLC fiber optic connectors for the new generation wireless base stations pulled far (WCDMA/TD-SCDMA/WiMax/GSM) tailored products that can be meet the FTTA(fiber to the top of the tower) program requirements for outdoor environment conditions and adverse weather conditions.



On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 1
DLC multimode Outdoor Protected Branch Cable Performance Parameter
Name
DLC multimode Outdoor Protected Branch Cable
Ferrule type
zirconia ceramics ferrule
Model
HYG-PA-RRU-MM-DLC-040
IL
≤0.3dB
Fiber model
Multimode 50/125
RL
≥35dB
Fiber core
2
Durability
≥1000 times
Jacket
7.0mm LSZH
Wavelength
850 1300nm
Length
40meter
Working temperature
-40℃~+80℃
DLC multimode Outdoor Protected Branch Cable Specification

Description
Standard
Cable Model
GYFJH-4B1  / GYFJH-2B1 / GYFJH-2A1

Number Optic-cable Core
2

Weight Kg/km
45.0

Outside Dia. mm
Φ7.0±0.2

Outer Sheath
material
LSZH
YD/T 1113-2001
color
BLACK

Fiber core
Fiber Type
G.652D

sheath color
white

Sheath material
LSZH

Out-Dia fiber for Tight layer
0.90±0.05 mm

Fiber specification
9/125(G652D)

Allowable Tension
Short term ≥500N

Long term ≥300N

Mini Bending radius
10D

Working life
≥25years


*all materials confirm to RoHS

Features

* IP65 protection, salt-mist proof
* Easy, reliable and cost-effective installation
* The connector of side-A is duplex LC, and side-B can be LC, SC or FC
* Thread structure guarantees the trusted connection

Applications:

3G 4G base station used
Aerospace & Defence
Equipment diagnosis
FO sensor
TTA ,FTTP, FTTX,WIMAX
BBU, RRU, RRH, LTE

On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 2
Detailed Images
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 3
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 4
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 5

Click here to see more products.

Packing & Delivery
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 6
On Sales 40M DLC Multimode Outdoor Armour Optical fiber Protected Branch Patch Cable for 3G Base Station 7

Reliable Package.

Each cable good packed in roll with label and test report, then use high quality carton to protect from strike and water.

Fast Delivery.

Fast and safty delivery cooperated with alibaba. 1~4 days to USA, 1~2 days to Japan, Korea and Southeast Asia, 4-7 days to Europe, South America and Africa.
